The past two decades have witnessed the explosion of activities in the field of surface enhanced Raman spectroscopy (SERS). SERS platforms employ nano-structures that excite plasmonic modes with large local electromagnetic fields localized within small gap spaces between each constituting feature. Although the research-oriented SERS platforms yield significant signal enhancements to identify even single molecules, practical SERS-based sensors have not been fully introduced yet. The main reason behind this absence is the need for a cost-effective and reliable manufacturing method for controllable fabrication of plasmonic nano-gaps over large areas. In this article, we introduced a novel manufacturing process that enables fast and scalable fabrication of highly uniform sub-10-nm gaps that could yield large SERS signals. In this process, a conventional electroplating technique is used to produce unique nano-mushroom antenna arrays on a conducting substrate, resulting in controllable gap spaces between mushroom heads. By understanding the nature of mushroom shape antenna formation, we demonstrated the control of inter-metallic gaps down to 5 nm. We showed that the manufactured nano-structures yield Raman enhancements more than 108. Providing such large SERS signals that are uniform over large areas, our cost-effective fabrication technique could be very critical to realize practical SERS devices.
Autor(es):CETIN, Arif E.
YILMAZ, Cihan
GALARRETA, Betty C.
ALTUG, Hatice
BUSNAINA, Ahmed
Año: 2020
Título de la revista: Plasmonics
Volumen: 15
Página inicial - Página final: 1165-1171
